Anhui FUTEN Environmental Protection Co.,Ltd.
7 Years
| Ask Lasest Price | |
| Brand Name : | FUTEN |
| Model Number : | FDPH 120 |
| Payment Terms : | T/T |
| Delivery Time : | 40 work days |
FDPH 120 In Pharmaceutical Processing Chemical Pump Oil Free Dry Screw Vacuum Pump
| MODEL | Suction capacity(m3/h) | Ultimate vacuum(Pa) | Power (KW) | Speed (rpm) | Inlet size(mm) | Outlet size(mm) | Operating liquid rates(L/min) | Weight(kg) |
| FDPH 120 | 100/120 | 2.7 | 2.2/3.0 | 2900/3500 | 40 | 40 | 2 | 180 |
| Specialties | |
| 1 | Oil-free and water-dry operation, it is providing a clean vacuum |
| 2 | No friction between the screw and the pump to ensures the life of the pump |
| 3 | Lower cost |
| 4 | Single stage design is easy for cleaning |
| 5 | The pipeline of pump is short that the gas could be discharge quickly |
| 6 | Special coating for handling toxic, corrosive and condensable gases |
| 7 | Simple design which is easy for maintenance |
| 8 | Low speed operation, low vibration, low noise |
| 9 | Mechanical seal is able to avoid leakage |
| Advantages | |
| 1 | To compare with common design, the power consumption is reduced by 30% which is saving a lot of utility costs |
| 2 | Reduce operating temperature to meet T4 standards |
| 3 | It is Improved vacuum volume to increases vacuum |
| 4 | Simple design to save installation space |
| 5 | Mainly flanged, simplify installation, reduce noise, and reduce coupling error |
|
|
